Heavy-Duty Steel Cf Training Frame

The Heavy-Duty Steel CF Training Frame is a multifunctional training rig engineered for demanding environments such as CrossFit gyms, strength training centers, and professional sports teams. Built from high-strength structural steel like Q345B or ASTM A500, it delivers exceptional load-bearing capacity, modular scalability, and long-term durability.

• Function: Multi-functional training fitness CF frame

• Application: General use in gyms, training centers, and teams

• Materials: Structural steel pipe

• Logo, Size, Color: Customizable

• Service: OEM support available

Core Features

1. High-Strength Steel & Load-Bearing Capacity

• Materials:

• Q345B low-alloy high-strength steel (≥ 345 MPa yield strength)

• ASTM A500 steel pipe (≥ 3mm wall thickness)

• Load Ratings:

• Pull-up bar: ≥ 500kg (tested 1000 dynamic cycles)

• Hanging piece: ≥ 300kg per side (J-hook, anti-slip design)

• Total structure: ≥ 1500kg (static test)

• Certification:

• Conforms to EN 957-1 International Fitness Equipment Standards

• Third-party laboratory tested and approved

2. Modular Design & Expandability

• Basic Frame Size:

• 2.2m (H) × 1.2m (W) × 1.8m (D), 90cm column spacing

• Optional Accessories:

• Pull-up bar (33mm diameter, anti-slip)

• Dumbbell rack (10 positions)

• Storage basket (50kg capacity)

• Expansion Capability:

• M12 high-strength bolts for double/multi-row setups

• Compatible with CrossFit attachments (elastic band anchors, rope brackets)

3. Ergonomics & Safety

• Bar Height Range:

• Low: 60cm (for deadlifts)

• High: 2.2m (for pull-ups & Olympic lifting)

• Safety Enhancements:

• Anti-slip foot pads (rubber, Ø10cm, Shore 70 ±5HA)

• Polyurethane corner guards (≥ 50J/cm² impact resistance)

• Electromagnetic brake system in rope area (≤ 0.2s response time)

4. Surface Finish & Durability

• Process:

• Acid pickling + phosphating (Sa2.5 rust removal level)

• Electrostatic powder coating (80–120 μm, 0-level adhesion)

• Performance Tests:

• Salt spray test: 720 hrs no rust (ASTM B117)

• Wear resistance: ≤ 50mg loss (Taber CS-10, 500g load)

5. Space Efficiency & Layout Flexibility

• Footprint:

• Single unit: 2.16 m² (2.2m × 0.98m including safety distance)

• Double row: 4.32 m² with 1.2m spacing

• Scenarios:

• Commercial gym: 4–6 units per 100 m², up to 50 trainees/hour

• Home gym: Requires minimum 3m × 3m space

Application Fields

1. Commercial Fitness Centers

• Needs: High usage, low maintenance, enhanced user experience

• Example:

• 10 sets installed by a gym chain

• 12% increase in membership renewals in 6 months

• 80–120 daily average uses per frame

2. Professional Sports Teams

• Needs: Precision, custom configuration

• Example:

• Used by National Weightlifting Team

• Force sensors with ±1% accuracy for real-time load tracking

• Rope module adjustable from 5–100kg in 0.5kg steps

3. Military Physical Training

• Needs: Extreme condition adaptability, rapid deployment

• Example:

• Deployed by Marine Corps Training Camp

• Foldable design (folded volume 0.8 m³)

• Tested for -40°C to +60°C desert operation

4. Corporate Wellness Programs

• Needs: Group training support, increased employee engagement

• Example:

• Tech company implemented “Daily Challenge” mode

• Average BMI reduced by 1.2 kg/m² among staff

• Integrated app for personalized training data and reports

FAQ

1. What type of training is this CF frame suitable for?

The Heavy-Duty Steel CF Training Frame is ideal for CrossFit, strength training, functional fitness, and military-style physical conditioning. Its modular design supports exercises such as pull-ups, barbell squats, bench presses, rope climbing, and more.

2. What materials are used in this training frame?

We use high-strength structural steel such as Q345B or ASTM A500 with a wall thickness of ≥3mm to ensure maximum durability and load-bearing capacity. All components are designed to meet international fitness equipment standards (EN 957-1).

3. How much weight can the frame support?

• Pull-up bar: Supports up to 500kg (tested for 1000 dynamic cycles)

• J-hooks or weight holders: Up to 300kg per side

• Total frame capacity: Over 1500kg static load

4. Can the structure be customized?

Yes. We support customization for:

• Size (height, width, depth)

• Color (powder coating options)

• Logo printing (OEM available)
  We also provide custom attachments and layout configurations based on client needs.

5. Is the frame modular and expandable?

Absolutely. The base frame can be expanded using M12 high-strength connectors, allowing for double-row or multi-station layouts. Compatible with standard CrossFit accessories like band anchors, rope brackets, and storage add-ons.

6. How is safety ensured during use?

• Anti-slip rubber footpads (diameter 10cm, Shore hardness 70 ± 5HA)

• Impact-resistant corner guards (polyurethane, ≥ 50J/cm²)

• Electromagnetic brake system in the rope zone (response time ≤ 0.2s)
  All safety features are tested and certified for commercial-grade use.

7. What kind of surface treatment does it have?

Each frame undergoes:

• Acid pickling + phosphating for rust removal

• Electrostatic powder coating (80–120 μm thickness)

• Passed 720-hour salt spray test (ASTM B117) and abrasion resistance testing

8. How much space does one unit occupy?

• Single unit footprint: Approx. 2.16 m²

• Double-row layout: Around 4.32 m², including safe spacing

• Minimum home gym space requirement: 3m x 3m
